Product Information
The LS-36™ panel, formerly known as the eco-FICIENT® Insulated R panel, utilizes a through-fastened attachment. The standard exterior skin is stucco-embossed but can be smooth if requested. The interior skin of the LS-36™ is roll formed with our standard stucco-embossed Mesa profile. LS-36™ is ideal for commercial applications.
Features
- Coverage Width – 36″
- Panel Attachment – Exposed Fastening System Panel
- Exterior Gauges – 26, 24, 22
- Interior Gauges – 26, 24, 22
- Minimum Slope – ½:12
- Exterior Finishes – Smooth; Embossed
- Interior Finishes – Stucco-embossed
- Exterior Coatings – Signature ® 200, Signature ® 300, Applied Finishes (for wall applications only)
- Interior Coatings – Igloo White (standard); Non-standard colors are also available for this panel
- Thicknesses – 1 1/2″, 2″, 2 1/2″, 3″, 4″, 5″, 6″
- Lengths – 8′-0″ to 50′-0″
- Orientation – Vertical or horizontal
